Description

After the wet material is inserted from one end of the dryer, under the flipping of the inner uniformly distributed plate reader, the material is evenly distributed and dispersed in the dryer, and fully contacts with the co current (counter current) hot air, accelerating the drying flow and mass transfer driving force. During the drying process, the material can be adjusted to move to the star shaped discharge valve at the other end of the dryer under the action of a tilted plate and hot air flow

1. In industries such as chemical, mining, and metallurgy, large particles and materials with high density are dried, such as ore, blast furnace slag, coal, metal powder, phosphate fertilizer, and ammonium sulfate.
2. Drying of powdered and granular materials with special requirements, such as HP foaming agent, distiller's grains residue, lightweight calcium carbonate, activated clay, magnetic powder, graphite, and pharmaceutical residue.
3. Materials that require low-temperature drying and require continuous drying in large quantities.

1. The rotary dryer has a high degree of mechanization and a large production capacity.
2. The fluid has low resistance through the cylinder and low functional consumption.
3. Strong adaptability to material characteristics.
4. Stable operation, low operating costs, and good uniformity of product drying.

model	Direct heating downstream type	Direct heating downstream type	Direct heating downstream type	Direct heating downstream type	Composite heating	Composite heating
Material type	ore	HP foaming agent	blast furnace slag	ammonium sulfate	phosphate fertilizer	coal
Processing capacity (kg/h)	1000	466	15000	20000	12000	5000
Discharge water content (%)	30	13	6	1.5	5	6.5
Final moisture content (%)	15	0.3	1	0.1	0.1	0.1
Average particle size (mm)	6.5	0.05	4.7	0.5-1.7	0.5	5
Material stacking density (kg/m3)	770	800	1890	1100	1500	750
Hot air volume (kg/h)	3900	5400	10750	9800	6500	16000
Inlet gas temperature (oC)	600	165	500	180	650	570
Material outlet temperature (oC)		42	100	70	80	75
Heating method	coal gas	Steam electric heating	heavy oil	JRF	heavy oil	heavy oil
loading coefficient		6.3	7	7.5	7.8	18
speed(rpm)	4	4	3.5	3	4	2
inclination	0.04	0.005	0.03	0.05	0.05	0.043
Number of copied boards	12	24	12	22	Outside the inner cylinder 8        Outside the inner cylinder 16	6 12
Drier diameter (m)	2.0	1.5	2	2.3	outer cylinder 2        inner cylinder 0.84	outer cylinder 2.4        inner cylinder 0.95
Dryer length (m)	20	12	17	15	10	16
Drive power (kw)	22	7.5	15	11	11	15
