FG series vertical boiling dryer

FG series vertical boiling dryer

This machine is mainly suitable for drying powder or granular materials in industries such as medicine, food, and chemical industry. Fluidized drying, fast heat and mass transfer; Operate under closed negative pressure, without dust flying; Using anti-static filtering materials for safe operation;

Description

Principle

Fluidized drying, fast heat and mass transfer; On the basis of the GFG high-efficiency boiling dryer, this equipment adds a drying straight cut to make the material easier to dry;

● Operate under closed negative pressure without dust flying;

● Using anti-static filtering materials for safe operation;

● The equipment has no dead corners, is thoroughly cleaned, and has no cross contamination;

● Meet GMP regulatory requirements.


Application

This machine is mainly suitable for drying powder or granular materials in industries such as medicine, food, and chemical industry.


Technical Parameter
modelunit3530601202003005001000
project
Raw material containerdiametermm300400700100012001400160018002200
volumeL1222100220420670100015002500
production capacitysmallkg/batch1.54153080100150250500
bigkg/batch4636721402403606001100
Steam consumptionkg/batch122370140211282366465800
air supplyM3/min0.30.30.30.60.60.90.90.91.5
fan powerkw2.245.51118.522304575
temperatureAutomatic adjustment at room temperature~120 ℃
Material yield%>99
TIMEmin15~30
Final moisture content%~0.2
noisedB≤75
Host heightmm210023002500300033003800400048006200

Note: Some parameters may be adjusted according to different materials during design, and the design shall prevail.
